Agile UC320 5-Axis CNC Machining Center for Responsive Milling and Complex Parts Production

responsive five-axis CNC machine

Agile 5axis-UC320 CNC machine

five-axis CNC machine with warranty

Place of Origin:

China

Brand Name:

Queenly

Certification:

GS, CE, RoHS, ISO 9001

Request A Quote

Agile UC320 5-Axis CNC Machining Center for Responsive Milling and Complex Parts Production

Product Details

Model NO.:

UC 320

Application:

Glass

Process Usage:

Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools

Movement Method:

Contour Control

Control Method:

Closed-Loop Control

Numerical Control:

CNC/MNC

Processing Precision:

0.01~0.02(mm)

Performance Classification:

High-End CNC Machine Tools

Condition:

New

Leading Time:

35days

Transport Package:

Pallet

Specification:

2550×3020×3000

Trademark:

Queenly

Origin:

China

Production Capacity:

50sets/Month

Highlight:

responsive five-axis CNC machine

Agile 5axis-UC320 CNC machine

five-axis CNC machine with warranty

Payment & Shipping Terms

Minimum Order Quantity

1sert

Price

USD50000-USD100000

Packaging Details

Standard export packing

Delivery Time

15-30DAYS

Payment Terms

T/T

Supply Ability

30set/mouth

RELATED PRODUCTS

Contact Now

Product Description

Product Introduction

A CNC milling machine is a highly automated manufacturing device controlled by computer numerical control (CNC) sy-stems. It utilizes rotating cutting tools to remove material from a workpiece, enabling precise and complex machining operations.

Equipped with advanced control panels, it allows for programming of various machining paths, depths, and speeds. Thi-s machine is capable of handling a wide range of materials, from metals like aluminum and steel to plastics and comp-osites.

Its precision makes it indispensable in industries such as aerospace, automotive, and mold-making, where intricate and accurate parts are required. Whether for prototyping or large-scale production, the CNC milling machine significantly en-hances manufacturing efficiency and part quality.

Key Features

Agile UC320 5-axis CNC machining center for responsive production
Suitable for milling, drilling, tapping, boring, contour machining, and surface finishing
Five-axis machining capability for complex surfaces and multi-angle parts
Reduces repeated clamping and improves machining consistency
CNC control system supports accurate and automated machining
Advanced control panel allows programming of paths, depths, speeds, and feed rates
Responsive operation supports quick adjustment for different machining tasks
Suitable for curved surfaces, inclined holes, deep cavities, molds, and impellers
Can process aluminum alloy, steel, stainless steel, cast iron, copper, plastics, and composites
Supports prototype machining, small-batch customization, and batch production
Ideal for aerospace, automotive, mold, machinery, electronics, and medical industries

Item	Unit	Parameter
C-axis rapid feed	rpm/min	260
X/Y/Z axis positioning accuracy	mm	±0.008/300mm(JIS std.)
A/C axis positioning accuracy	arcsec	6 arcsec
Max. tool length	mm	150
Max. tool weight	Kg	8
Tool magazine type	-	Arm type tool magazine
Tool magazine capacity	-	32
Max. tool diameter	mm	Φ80
Air supply requirement	kg/cm	6
Machine footprint	mm	320028002600
Power requirement	Kw	20
Machine weight	kg	6000

C-axis rapid feed	rpm/min	260
X/Y/Z axis positioning accuracy	mm	±0.008/300mm (JIS std.)
A/C axis positioning accuracy	arcsec	6 arcsec
Max. tool length	mm	150
Max. tool weight	Kg	8
Tool magazine type	-	Arm type tool magazine
Tool magazine capacity	-	32
Max. tool diameter	mm	Φ80
Air supply requirement	kg/cm	6
Machine footprint	mm	320028002600
Power requirement	Kw	20
Machine weight	kg	6000

A-axis (Tilting)
Rated speed (rpm)	rpm	100
Max. speed (rpm)	rpm	200
Rated torque (N·m)	N·m	272
Max. torque (N·m)	N·m	461
Rated power (kW)	kW	2.65
Brake pressure (MPa)	MPa	0.5 - 0.6
Brake torque (N·m)	N·m	≥400
C-axis (Rotary)
Rated speed (rpm)	rpm	180
Max. speed (rpm)	rpm	260
Rated torque (N·m)	N·m	68
Max. torque (N·m)	N·m	260
Rated power (kW)	kW	1.3
Brake pressure (MPa)	MPa	0.5 - 0.6
Brake torque (N·m)	N·m	≥200
Others:
Table diameter	mm	320
Max. workpiece diameter	mm	500
Tilting range	deg	±110°
Keyway width	mm	12H7
Max. workpiece weight	kg	120

FAQ

1. What is the UC320 5-Axis CNC Machining Center used for?

The UC320 5-Axis CNC Machining Center is mainly used for precision milling, drilling, tapping, boring, contour machining, complex surface processing, mold machining, prototype production, and customized industrial parts manufacturing.

2. Why is the UC320 considered an agile CNC machine?

The UC320 supports flexible five-axis machining, programmable tool paths, quick process adjustment, and multi-material processing. These features help manufacturers respond quickly to different production requirements.

3. What are the advantages of five-axis CNC machining?

Five-axis CNC machining allows the cutting tool to approach the workpiece from multiple angles. This reduces repeated clamping, minimizes positioning errors, improves machining consistency, and makes complex parts easier to process.

4. What materials can this machine process?

The UC320 can process aluminum alloy, steel, stainless steel, cast iron, copper, plastics, composites, and other industrial materials. The actual machining capability depends on spindle power, cutting tools, machine configuration, and workpiece requirements.

5. What machining functions does the UC320 support?

The UC320 supports milling, drilling, tapping, boring, contour machining, surface finishing, multi-angle machining, and complex parts processing according to different production needs.

6. How can I choose the most suitable machine?

Please provide your workpiece material, processing size, required accuracy, machining functions, production capacity, or machine model. You can also send product drawings or pictures, and our team will recommend the most suitable machine configuration.

7. Can the machine be customized according to customer requirements?

Yes. We support customization of machining range, spindle power, spindle speed, control system, tool magazine, fixture configuration, cooling system, chip removal system, protective cover, and other machine specifications according to customer production needs.
