Precision CNC Milling Machine for Professional Manufacturing Needs

Precision CNC Milling Machine for Professional Manufacturing Needs

Precision CNC milling machine

Professional CNC milling equipment

Manufacturing CNC milling machine

Certification:

GS, CE, RoHS, ISO 9001

Contact Us
Request A Quote
Product Details
Model NO.:
QNCY26157
Application:
Glass
Process Usage:
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method:
Contour Control
Control Method:
Closed-Loop Control
Numerical Control:
CNC/MNC
Processing Precision:
0.01~0.02(mm)
Performance Classification:
High-End CNC Machine Tools
Condition:
New
Leading Time:
60days
X-Axis Travel:
500mm
Y-Axis Travel:
750mm
Z-Axis Travel:
400mm
Transport Package:
Pallet
Specification:
2550×3020×3000
Trademark:
Queenly
Origin:
China
HS Code:
84571010
Production Capacity:
50sets/Month
Highlight:

Precision CNC milling machine

,

Professional CNC milling equipment

,

Manufacturing CNC milling machine

Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
US $61,000 / set
RELATED PRODUCTS
Contact Us
Contact Now
Product Description
Precision CNC Milling Machine for Professional Manufacturing Needs 0
Product Introduction
Precision CNC Milling Machine for Professional Manufacturing Needs 1

A CNC milling machine is a highly automated manufacturing device controlled by computer numerical control (CNC) sy-stems. It utilizes rotating cutting tools to remove material from a workpiece, enabling precise and complex machining operations.

Equipped with advanced control panels, it allows for programming of various machining paths, depths, and speeds. Thi-s machine is capable of handling a wide range of materials, from metals like aluminum and steel to plastics and comp-osites.

Its precision makes it indispensable in industries such as aerospace, automotive, and mold-making, where intricate and accurate parts are required. Whether for prototyping or large-scale production, the CNC milling machine significantly en-hances manufacturing efficiency and part quality.

Precision CNC Milling Machine for Professional Manufacturing Needs 2
Precision CNC Milling Machine for Professional Manufacturing Needs 3
Precision CNC Milling Machine for Professional Manufacturing Needs 4
Precision CNC Milling Machine for Professional Manufacturing Needs 5
Precision CNC Milling Machine for Professional Manufacturing Needs 6
Precision CNC Milling Machine for Professional Manufacturing Needs 7
ItemUnitParameter
C-axis rapid feedrpm/min260
X/Y/Z axis positioning accuracymm±0.008/300mm(JIS std.)
A/C axis positioning accuracyarcsec6 arcsec
Max. tool lengthmm150
Max. tool weightKg8
Tool magazine type-Arm type tool magazine
Tool magazine capacity-32
Max. tool diametermmΦ80
Air supply requirementkg/cm6
Machine footprintmm320028002600
Power requirementKw20
Machine weightkg6000
C-axis rapid feedrpm/min260
X/Y/Z axis positioning accuracymm±0.008/300mm (JIS std.)
A/C axis positioning accuracyarcsec6 arcsec
Max. tool lengthmm150
Max. tool weightKg8
Tool magazine type-Arm type tool magazine
Tool magazine capacity-32
Max. tool diametermmΦ80
Air supply requirementkg/cm6
Machine footprintmm320028002600
Power requirementKw20
Machine weightkg6000
A-axis (Tilting)

Rated speed (rpm)rpm100
Max. speed (rpm)rpm200
Rated torque (N·m)N·m272
Max. torque (N·m)N·m461
Rated power (kW)kW2.65
Brake pressure (MPa)MPa0.5 - 0.6
Brake torque (N·m)N·m≥400
C-axis (Rotary)

Rated speed (rpm)rpm180
Max. speed (rpm)rpm260
Rated torque (N·m)N·m68
Max. torque (N·m)N·m260
Rated power (kW)kW1.3
Brake pressure (MPa)MPa0.5 - 0.6
Brake torque (N·m)N·m≥200
Others:

Table diametermm320
Max. workpiece diametermm500
Tilting rangedeg±110°
Keyway widthmm12H7
Max. workpiece weightkg120
Main products
Precision CNC Milling Machine for Professional Manufacturing Needs 8
Company Profile
Precision CNC Milling Machine for Professional Manufacturing Needs 9

Queenly Machine established in Fujian, specializing in a wide range of precision CNC machine tools, including high-pre-cision grinding centers, ultra-precision surface grind- ers, optical milling and grinding centers, flexible polishing machin-es, various machining centers, CNC cutting tools, power chucks, hydraulic cylinder, drilling and tapping ma- chine, pack-aging machinery, booster cylinder, copper, etc.

Our company adheres to a talent-oriented philosophy and is dedicated to the research and industrialization of critical and bottleneck technologies. Its main business focuses on the R&D, manufacturing, and sales of high-end CNC mach-ine tools and ultra-preci- sion optical components.

All of our products are independently designed and manufactured by our team, based on more than decades of exper-tise in processing hard and brittle materials. In addition, our company has independently developed a five-axis CNC co-ntrol system as well as multiple sets of auxiliary machining software.

We have developed the first 6-axis Coordinate Advance Milling and (Deep Hole) Drilling machine in Asia. This establish-ment has been recognized by different expertise as coun- try leading-edge technology and access to a number of natio-nal patents. In Multi-func- tion Deep Hole Drilling Machine, we have been recognized by majority of the customer as the Leader of quality and craftsmanship throughout the country.

During the process of R&D, Production and Market development, we are also using our machine to master the frst-hand information. Be bold and innovative, ever-improving, continue to explore and of course listen to our customer comment for quality improve- ment. We always use the customer point of view to modify the machine become more suitable and user friendly.

Queenly targets the world mould making edge - leading technology, continue to ex- plore, higher accuracy and perfect quality, thus enable our customers to be equipped with the most suitable machines.

Nowadays, our products exported all over the world: USA, Australia, Brazil, Bangladesh, Canada, India, Korea, Malaysia, Portugal, Thailand, Taiwan, UK and so on.

In the future, with the intelligent manufacturing, we would like to work by your side and provide you with different solu-tion to conquer any challenges.
