High-Precision CNC Deep Hole Drilling Machine for Industrial Metal Processing and Accurate Hole Machining
High-Precision CNC Deep Hole Drilling Machine for Industrial Metal Processing and Accurate Hole Machining
CNC deep hole drilling machine
industrial precision drilling machine
heavy-duty CNC drilling equipment
Place of Origin:
China
Brand Name:
Queenly
Certification:
CE, ISO 9001
Contact Us
Request A Quote
Product Details
Model NO.:
2.6HS
Structure:
Horizontal Drilling Machine
Layout:
Horizontal
Controlling Mode:
CNC
Number Of Shaft:
3
Hole Diameter:
50-100mm
Automatic Grade:
Automatic
Precision:
High Precision
Condition:
New
Size:
4700 X 4850 X 3100mm
Machining Hole Diameter:
3~35mm
Machining Depth:
1200mm
Worktable Horizontal (X):
1300
Spindle Vertical (Y):
1200
Max. Spindle Speed:
6000rpm
Spindle Feed Speed:
0~3000mm/Min
Spindle Motor:
11kw
Total Power Requirement:
35kw
Worktable Max. Loading Capacity:
8ton
Worktable Size:
1500X1050
Coolant Pressure:
1~8MPa
Rate Of Flow:
6~110 L/Min
CNC System:
Fanuc/Syntec
Transport Package:
Container
Specification:
11 Ton
Trademark:
QUEENLY
Origin:
China
HS Code:
8459210000
Production Capacity:
800pieces/Year
Highlight:
CNC deep hole drilling machine
,industrial precision drilling machine
,heavy-duty CNC drilling equipment
Payment & Shipping Terms
Minimum Order Quantity
1sert
Price
USD50000-USD100000
Packaging Details
Standard export packing
Delivery Time
15-30DAYS
Payment Terms
T/T
Supply Ability
30set/mouth
RELATED PRODUCTS
Contact Us
Contact Now
Product Description
Product Introduction
The High-Precision CNC Deep Hole Drilling Machine is a professional machining solution designed for deep-hole drilling, accurate hole machining, mold processing, hydraulic component manufacturing, automotive parts production, aerospace components, machinery parts, and industrial metal processing applications. Equipped with a CNC control system and rigid machine structure, this machine provides stable drilling accuracy, reliable hole straightness, smooth inner hole quality, and efficient long-depth drilling performance.
Deep-hole drilling requires strong machine rigidity, precise feed control, stable spindle performance, high-efficiency coolant supply, and reliable chip evacuation. This CNC deep hole drilling machine is designed to reduce hole deviation, improve machining consistency, and maintain stable cutting performance during long-depth hole processing.
The machine is suitable for processing steel, alloy steel, stainless steel, cast iron, aluminum alloy, copper alloy, mold steel, and other industrial metal materials. It can be used for mold water channels, oil holes, cooling holes, hydraulic valve holes, shaft holes, cylinder holes, and other precision deep-hole structures.
The CNC control system allows operators to set drilling depth, spindle speed, feed rate, machining path, and process parameters according to different workpieces. This helps improve machining repeatability, reduce manual operation errors, and support stable production for single-piece machining, small-batch production, and mass manufacturing.
FAQ
1. What is a CNC Deep Hole Drilling Machine used for?
It is mainly used for deep-hole drilling, long-depth hole machining, mold water channel drilling, hydraulic valve hole processing, shaft hole drilling, oil hole machining, cooling hole processing, and industrial metal part production.
2. What materials can this machine process?
It can process steel, alloy steel, stainless steel, cast iron, aluminum alloy, copper alloy, mold steel, and other industrial metals depending on drill type, coolant condition, spindle power, feed rate, and workpiece hardness.
3. Why is CNC control important for deep-hole drilling?
CNC control helps accurately manage drilling depth, feed speed, spindle speed, machining path, and process parameters. This improves repeatability, hole accuracy, and production consistency.
4. What are the advantages of CNC deep-hole drilling?
CNC deep-hole drilling provides better hole straightness, smoother inner hole surface, more stable drilling accuracy, reduced manual error, and better consistency for batch production.
5. Why is coolant important in deep-hole drilling?
Coolant helps cool the cutting tool, reduce friction, flush chips out of the hole, improve inner hole surface quality, and protect the tool during long-depth drilling.
6. Can the machine be customized?
Yes. Machine travel, drilling depth, spindle configuration, coolant system, clamping method, control system, and workpiece support structure can be customized according to production requirements.
7. What information is needed for quotation?
Please provide workpiece material, hole diameter, drilling depth, required accuracy, workpiece size, maximum workpiece weight, production quantity, drawing, and application industry.
