Heavy-Duty CNC Drilling Machine
CNC drilling machine for metal
heavy-duty CNC drill press
industrial CNC drilling equipment
Certification:
CE, ISO 9001
Contact Us
Request A Quote
Product Details
Model NO.:
3.6HD
Structure:
Horizontal Drilling Machine
Layout:
Horizontal
Controlling Mode:
CNC
Number Of Shaft:
3
Hole Diameter:
50-100mm
Automatic Grade:
Automatic
Precision:
High Precision
Condition:
New
Size:
4700 X 4850 X 3100mm
Machining Hole Diameter:
3~35mm
Machining Depth:
1200mm
Worktable Horizontal (X):
1300
Spindle Vertical (Y):
1200
Max. Spindle Speed:
6000rpm
Spindle Feed Speed:
0~3000mm/Min
Spindle Motor:
11kw
Total Power Requirement:
35kw
Worktable Max. Loading Capacity:
8ton
Worktable Size:
1500X1050
Coolant Pressure:
1~8MPa
Rate Of Flow:
6~110 L/Min
CNC System:
Fanuc/Syntec
Transport Package:
Container
Specification:
11 Ton
Trademark:
QUEENLY
Origin:
China
HS Code:
8459210000
Production Capacity:
800pieces/Year
Highlight:
CNC drilling machine for metal
,heavy-duty CNC drill press
,industrial CNC drilling equipment
Payment & Shipping Terms
Minimum Order Quantity
1 SET
Price
US $100,000 / SET
RELATED PRODUCTS
Contact Us
Contact Now
Product Description
Product Introduction
FAQ
-
What's your main products of your company?
We specialized in a wide range of precision CNC machine tools, including high-precision grinding centers, ultra-precision surface grinders, optical milling and grinding centers, flexible polishing machines, various machining centers, CNC cutting tools, power chucks, hydraulic cylinder, drilling and tapping machine, packaging machinery, booster cylinder, copper, etc.
-
What kind of controls do you use on machines?
Siemens, GSK,Fanuc etc. You can choose according too your requirements
-
How can I choose the most suitable machines ?
Please tell me the model or parameter you are interested in, vwe can provide you with the best price and quality. You can also send us product pictures and we will choose the meost suitable machine for you.
-
What machining functions do your machining centers support?
Our machining centers support drilling, tapping, milling, boring, and turning functions, with multi-axis options (such as 3-axis, 4-axis, and 5-axis) to meet the needs of complex workpiece machining.
-
Can the machines be customized according to customer requirements?
Absolutely! We support customization of machining range, spindle power, automation level, and fixture and tooling configurations to meet your production needs.
-
What payment methods do you accept?
We accept various payment methods, including T/T bank transfers and Letters of Credit (L/C). Please contact us if you have other requirements.
-
How long is the delivery time?
Standard models usually require 30-45 days for delivery. For customized models, the delivery time may take 60 days or longer, depending on the complexity. The exact delivery time will be confirmed with the order.
-
How are the machines packaged and transported?
Our machines are packaged with waterproof and rustproof materials, reinforced with sturdy wooden crates, suitable for sea and long-distance transportation to ensure the products arrive at your specified location in perfect condition..
