CNC Gantry Machining
>
Cost-Effective CNC Milling Machine for Precision Metal, Plastic and Wood Parts Manufacturing
Cost-Effective CNC Milling Machine for Precision Metal, Plastic and Wood Parts Manufacturing
affordable CNC machines
budget CNC milling machines
low-cost CNC equipment
Place of Origin:
China
Brand Name:
Queenly
Certification:
GS, CE, RoHS, ISO 9001
Contact Us
Request A Quote
Product Details
Model NO.:
GTE3030C
Application:
Metal
Process Usage:
Metal-Cutting CNC Machine Tools, Metal-Forming CNC Machine Tools
Movement Method:
Contour Control
Control Method:
Closed-Loop Control
Numerical Control:
CNC/MNC
Processing Precision:
0.01~0.02(mm)
Performance Classification:
High-End CNC Machine Tools
Condition:
New
Transport Package:
Pallet
Specification:
4550*3827*3245
Trademark:
Queenly
Origin:
China
HS Code:
84601100
Production Capacity:
200sets/Month
Highlight:
affordable CNC machines
,budget CNC milling machines
,low-cost CNC equipment
Payment & Shipping Terms
Minimum Order Quantity
1sert
Price
USD50000-USD100000
Packaging Details
Standard export packing
Delivery Time
15-30DAYS
Payment Terms
T/T
Supply Ability
30set/mouth
RELATED PRODUCTS
Contact Us
Contact Now
Product Description
Product Introduction
A CNC (Computer Numerical Control) milling machine is a precision - oriented, automated tool reshaping modern manufacturing. It operates by executing commands from a pre - written computer program, often generated from a CAD (Computer - Aided Design) model via CAM (Computer - Aided Manufacturing) software. This machine consists of key components. The control panel, acting as the "brain," interprets digital instructions and directs the machine's actions. The axis system, typically including the X, Y, and Z axes, determines the cutting tool's movement directions, while the spindle holds and rotates the cutting tool at varying speeds for material removal. The work table securely fastens the workpiece, ensuring stability during machining. CNC milling machines can create diverse shapes and perform operations like face milling, pocket milling, and drilling. They are highly versatile, working with materials such as metals, plastics, and wood. Their advantages are significant: they offer high precision, enabling the production of parts with tight tolerances; they ensure consistency and repeatability, crucial for mass - producing identical components; and they boost productivity as they can run continuously with minimal human intervention. These qualities make CNC milling machines indispensable across industries, from aerospace and automotive to medical device manufacturing and prototyping.
|
CNC milling machine GTE3030C Machine Tool Parameters:
|
|
|
X-axis travel (moving beam forward/backward travel):
|
3000 mm
|
|
Y-axis travel (saddle left/right travel): 3000 mm
|
3000mm
|
|
Z-axis travel (milling head up/down travel):
|
1500 mm
|
|
Distance from spindle nose to worktable:
|
100–1600 mm
|
|
Distance between two columns:
|
4200–5700 mm
|
|
Worktable size:
|
3500 * 2800 mm
|
|
Worktable load capacity:
|
8 tons
|
|
Maximum spindle speed:
|
6000 rpm
|
|
Maximum spindle torque:
|
300 N·m
|
|
Rotation angle:
|
A = ±180°, C = ±360°
|
|
Angular positioning accuracy:
|
A = ±5 sec; C = ±5 sec
|
|
Minimum indexing angle:
|
0.0001°
|
|
Rapid feed rate: X, Y:
|
20 / 50 m/min; Z: 20 m/min
|
|
Cutting feed rate:
|
10 m/min
|
|
Number of tools:
|
32 pcs
|
|
Total machine power:
|
110 kW
|
|
Machine dimensions (L * W * H):
|
7600 * 8100 * 6150 mm
|
|
Machine weight:
|
52 tons
|
|
Control system:
|
FANUC / Heidenhain / SIEMENS
|
FAQ
1. What is a CNC Milling Machine used for?
A CNC Milling Machine is mainly used for milling, drilling, face milling, pocket milling, contour cutting, and precision machining of customized parts. It is suitable for producing molds, mechanical parts, automotive components, medical device parts, prototypes, and industrial components.
2. How does a CNC milling machine work?
A CNC milling machine works by following a pre-written computer program. The design is usually created with CAD software and converted into tool paths through CAM software. The CNC control system then directs the spindle and machine axes to complete the machining process accurately.
3. What materials can this CNC milling machine process?
This machine can process various materials, including steel, aluminum alloy, copper, plastic, wood, and other industrial materials. The actual processing capability depends on spindle power, cutting tools, machine rigidity, and workpiece requirements.
4. What are the advantages of CNC milling?
CNC milling provides high precision, strong repeatability, stable part quality, and improved production efficiency. It reduces manual operation and is suitable for both small-batch custom production and mass production of identical parts.
5. What control systems do you use on your machines?
We can provide different control systems according to customer requirements, such as Siemens, GSK, FANUC, and other reliable CNC control brands.
6. How can I choose the most suitable machine?
Please tell us the machine model, technical parameters, workpiece material, processing size, or production requirements you are interested in. You can also send us product pictures or drawings, and our team will recommend the most suitable machine with competitive price and reliable quality.
7. Can the machines be customized according to customer requirements?
Yes. We support customization of machining range, spindle power, worktable size, control system, tooling system, fixture configuration, automation level, protective cover, chip removal system, and other machine specifications according to your production needs.
