Horizontal Cam Exchange Table

Horizontal Cam Exchange Table

horizontal cam exchange table

cam exchange table with warranty

industrial cam exchange table

Contact Us
Request A Quote
Product Details
Model NO.:
BC Head
Jaw Type:
Master Jaw
Power:
Hydraulic
Structure:
Solid
Material:
Carbon Steel
Type:
Special Chuck
Jaw Width:
100
Jaw Height:
30
Jaw Open:
100
Transport Package:
Case
Specification:
Made Of High Quality Steel
Trademark:
QUEENLY
Origin:
China
HS Code:
8466200000
Production Capacity:
4000PCS/Year
Highlight:

horizontal cam exchange table

,

cam exchange table with warranty

,

industrial cam exchange table

Payment & Shipping Terms
Minimum Order Quantity
1 SET
Price
US $6,000-7,000 / S
RELATED PRODUCTS
Contact Us
Contact Now
Product Description
Horizontal Cam Exchange Table 0
Product Introduction
Main products
Horizontal Cam Exchange Table 1
Company Profile
Horizontal Cam Exchange Table 2

Queenly Machine established in Fujian, specializing in a wide range of precision CNC machine tools, including high-pre-cision grinding centers, ultra-precision surface grind- ers, optical milling and grinding centers, flexible polishing machin-es, various machining centers, CNC cutting tools, power chucks, hydraulic cylinder, drilling and tapping ma- chine, pack-aging machinery, booster cylinder, copper, etc.

Our company adheres to a talent-oriented philosophy and is dedicated to the research and industrialization of critical and bottleneck technologies. Its main business focuses on the R&D, manufacturing, and sales of high-end CNC mach-ine tools and ultra-preci- sion optical components.

All of our products are independently designed and manufactured by our team, based on more than decades of exper-tise in processing hard and brittle materials. In addition, our company has independently developed a five-axis CNC co-ntrol system as well as multiple sets of auxiliary machining software.

We have developed the first 6-axis Coordinate Advance Milling and (Deep Hole) Drilling machine in Asia. This establish-ment has been recognized by different expertise as coun- try leading-edge technology and access to a number of natio-nal patents. In Multi-func- tion Deep Hole Drilling Machine, we have been recognized by majority of the customer as the Leader of quality and craftsmanship throughout the country.

During the process of R&D, Production and Market development, we are also using our machine to master the frst-hand information. Be bold and innovative, ever-improving, continue to explore and of course listen to our customer comment for quality improve- ment. We always use the customer point of view to modify the machine become more suitable and user friendly.

Queenly targets the world mould making edge - leading technology, continue to ex- plore, higher accuracy and perfect quality, thus enable our customers to be equipped with the most suitable machines.

Nowadays, our products exported all over the world: USA, Australia, Brazil, Bangladesh, Canada, India, Korea, Malaysia, Portugal, Thailand, Taiwan, UK and so on.

In the future, with the intelligent manufacturing, we would like to work by your side and provide you with different solu-tion to conquer any challenges.

Horizontal Cam Exchange Table 3
Cooperative Brand
Horizontal Cam Exchange Table 4
Our Services
Horizontal Cam Exchange Table 5
Certifications
Horizontal Cam Exchange Table 6
Packaging & Shipping
Horizontal Cam Exchange Table 7
FAQ
Horizontal Cam Exchange Table 8
Horizontal Cam Exchange Table 9
Horizontal Cam Exchange Table 10
Horizontal Cam Exchange Table 11
Horizontal Cam Exchange Table 12
Horizontal Cam Exchange Table 13
Horizontal Cam Exchange Table 14
Horizontal Cam Exchange Table 15
Horizontal Cam Exchange Table 16
Horizontal Cam Exchange Table 17
Item
Unit
Data
Worktable Size
mm
ø170
Worktable Height (Horizontal)
mm
260
Standard Motor Specification (Straight Shaft Motor) (Customizable for other brands/models) - Rotation Axis
-
FANUC BIS4, MITSUBISHI HG96
Standard Motor Specification (Straight Shaft Motor) (Customizable for other brands/models) - Tilt Axis
-
FANUC BIS8, MITSUBISHI HG104
T-slot Width
mm
12H7
Locating Key Width
mm
18h7/14h7
Minimum Angle Setting Unit
deg
0.001
Total Reduction Ratio - Rotation Axis
-
1:40
Total Reduction Ratio - Tilt Axis
-
1:50
Repeat Precision (Rotation Axis)
arc.sec
8
Repeat Precision (Tilt Axis)
arc.sec
15
Indexing Precision (Rotation Axis)
arc.sec
20
Indexing Precision (Tilt Axis)
arc.sec
40
Locking Method (Hydraulic)
MPa
3.5±0.5
Locking Torque
N·m
390
Product Weight
kg
155
