High-Speed Heavy-Cutting Gear Head Vertical Machining Center for Steel Parts, Castings and High-Torque Milling
High-Speed Heavy-Cutting Gear Head Vertical Machining Center for Steel Parts, Castings and High-Torque Milling
Place of Origin:
China
Brand Name:
Queenly
Certification:
GS, CE, RoHS, ISO 9001
Contact Us
Request A Quote
Product Details
Model NO.:
UT260
Application:
Glass
Process Usage:
Metal-Cutting CNC Machine Tools
Movement Method:
Contour Control
Control Method:
Closed-Loop Control
Numerical Control:
CNC/MNC
Processing Precision:
0.01~0.02(mm)
Performance Classification:
High-End CNC Machine Tools
Condition:
New
Leading Time:
35days
Transport Package:
Pallet
Specification:
2550×3020×3000
Trademark:
Queenly
Origin:
China
Production Capacity:
50sets/Month
Payment & Shipping Terms
Minimum Order Quantity
1sert
Price
USD50000-USD100000
Packaging Details
Standard export packing
Delivery Time
15-30DAYS
Payment Terms
T/T
Supply Ability
30set/mouth
RELATED PRODUCTS
Contact Us
Contact Now
Product Description
High-Speed Heavy-Cutting Gear Head Vertical Machining Center for Steel Parts, Castings and High-Torque Milling
Product Overview
The High-Speed Heavy-Cutting Gear Head Vertical Machining Center is a high-rigidity CNC machining solution engineered for heavy-duty milling, drilling, tapping, boring, rough machining, semi-finishing, and precision finishing operations. Designed specifically for steel parts, castings, mold bases, machinery components, and large industrial workpieces, this machine delivers exceptional torque output, stable cutting performance, and reliable machining accuracy under demanding production conditions.
Unlike conventional belt-driven vertical machining centers, this gear head model provides superior cutting force and enhanced material removal capabilities. The gear transmission structure ensures powerful low-speed torque while maintaining stable spindle operation, making it ideal for deep cutting, large-diameter tool machining, heavy milling, and high-load metal processing applications.
The machine features a rigid vertical structure with reinforced bed construction, stable column design, precision guideways, and robust worktable support. This advanced structural design minimizes vibration during heavy cutting operations and ensures consistent machining performance when processing hard materials, thick plates, cast iron parts, steel components, and mold materials.
Key Features
- High-speed heavy-cutting vertical machining center with gear head spindle
- Gear transmission structure provides strong torque for heavy-duty milling
- Suitable for steel parts, castings, mold bases, plates, and heavy workpieces
- Rigid machine structure helps reduce vibration during high-load cutting
- Supports rough machining, semi-finishing, and precision finishing
- CNC control system provides accurate and automated machining
- Suitable for milling, drilling, tapping, boring, slotting, chamfering, and contour machining
- Stable worktable improves workpiece clamping and machining quality
- Optional automatic tool changer improves multi-process machining efficiency
- Coolant system and chip conveyor support continuous production
- Suitable for steel, cast iron, stainless steel, aluminum alloy, copper, and mold materials
- Customizable spindle power, spindle speed, worktable size, tool magazine, control system, and protection system
Product Images
Technical Specifications
| Item | Unit | VM850G | VM1050G | VM1050GII | VM1270GII |
|---|---|---|---|---|---|
| Travel X/Y/Z | mm | 800 * 500 * 550 | 1000 * 500 * 550 | 1000 * 500 * 550 | 1200 * 700 * 650 |
| Distance from spindle nose to worktable | mm | 110–680 | 110–680 | 110–680 | 130–780 |
| Worktable size | mm | 1000 * 500 | 1100 * 500 | 1100 * 500 | 1350 * 680 |
| Max. load capacity | kg | 500 | 800 | 800 | 1200 |
| T-slot size | mm | 5–18 * 90 | 5–18 * 90 | 5–18 * 90 | 5–18 * 120 |
| Max. spindle speed | r/min | 8000 / 12000 | 8000 / 12000 | 6000 / 8000 | 6000 / 8000 |
| Spindle power | kW | 7.5–11 / 11–15 | 7.5–11 / 11–15 | 11–15 / 15–18.5 | 11–15 / 15–18.5 |
| Rapid traverse speed X/Y/Z | m/min | 36 * 36 * 36 | 36 * 36 * 36 | 36 * 36 * 36 | 30 * 30 * 30 |
| Tool shank type | — | BT40 | BT40 | BT50 | BT50 |
| Tool magazine capacity | pcs | 24 | 24 | 24 | 24 |
| Tool change time | sec | 2.5 | 2.5 | 3.5 | 3.5 |
| NC system | — | SYNTEC / FANUC | SYNTEC / FANUC | SYNTEC / FANUC | SYNTEC / FANUC |
Frequently Asked Questions
What is the High-Speed Heavy-Cutting Gear Head Vertical Machining Center used for?
It is mainly used for heavy-duty milling, drilling, tapping, boring, slotting, chamfering, and precision machining of steel parts, castings, mold bases, machinery parts, and large industrial workpieces.
What is the advantage of a gear head spindle?
A gear head spindle provides stronger torque output than ordinary belt-driven spindle structures. It is more suitable for deep cutting, large-diameter tools, heavy milling, and machining hard materials.
Why is this machine suitable for heavy cutting?
The machine combines a rigid vertical structure, reinforced bed, stable worktable, powerful gear head spindle, precision guideways, and reliable CNC control. These features help reduce vibration and maintain machining accuracy during high-load cutting.
What materials can this machine process?
This machining center can process steel, cast iron, stainless steel, aluminum alloy, copper, mold materials, and other industrial materials. The actual processing capability depends on spindle power, cutting tools, machine configuration, and workpiece requirements.
What machining functions does the machine support?
The machine can support milling, drilling, tapping, boring, slotting, chamfering, contour machining, rough machining, semi-finishing, and precision finishing according to different production requirements.
What industries use this machine?
It is widely used in machinery manufacturing, mold making, automotive parts production, casting processing, heavy equipment manufacturing, industrial base machining, and custom metal parts production.
Can the machine be customized according to customer requirements?
Yes. We support customization of machining range, spindle power, spindle speed, worktable size, control system, tool magazine, fixture configuration, coolant system, chip removal system, protective cover, and other machine specifications according to production needs.
